CCTV investigations
Pipelines from 100 mm to 2,500 mm in diameter, with continuous runs up to 500 m using HD 1080p mainline crawlers.
CCTV Inspections & Reports
Robotic pipeline surveys with WSA-compliant condition assessments and defect coding.
Overview
About the service
Internal pipeline inspection uses robotic CCTV crawlers alongside sonar and laser sensors to verify structural integrity, confirm as-built geometry and grade defects. Every survey is coded against national standards — typically WSA05 or NZPIM — and delivered as a detailed condition report.
Those reports give asset owners the evidence they need to prioritise rehabilitation, plan maintenance and defend service levels — reducing the risk of failures, floods and insurance claims.
Why SSA
What sets our cctv inspections & reports apart
Our systems handle sewer and stormwater assets of every size, from small-diameter house connections through to trunk mains. Six-wheel-drive CCTV crawlers navigate bends, drops and pits with ease, and every survey is coded in Wincan against WSA and IPWEA standards.
We pair inspection with rehabilitation recommendations, so you don't just get a list of defects — you get a scoped, prioritised path forward.
In the field
Real crews. Real jobs. Real results.
A look at our teams delivering cctv inspections & reports on live sites across Australia.
SSA CCTV inspection truck on-site with mainline crawler deployed
1 / 5
Capabilities
What's included
Multi-sensor inspection (MSI) profiling
HD panoramic camera, sonar and infrared laser combined for empirical condition data without confined-space entry.
Laser profiling
Automated pipe profiling from 150 mm to 3 m diameter for precise ovality, deflection and defect measurement.
Push-camera surveys
Waterproof high-resolution cameras for narrow-diameter drains, connections and hard-to-reach sewage assets under 150 mm.
Fixed zoom cameras
Powerful lighting and optical zoom for rapid triage of structural issues in mainlines from DN225 to DN2250.
Jet cameras
Camera heads mounted to jet/vac units capture pre- and post-clean footage in the same visit.
Boat surveys
Floating CCTV rigs with 360° optics, laser and sonar for large-diameter, high-flow trunk mains.
Have a project that needs cctv inspections & reports?
Send us the address, the scope and the timeframe. A project manager will respond within one business hour with a fixed proposal and a mobilisation date.
